Caterpillar D5N XL, 2005 year model, 3251 hours, with ripper (10071)

Caterpillar D5N XL
Click on a thumbnail to enlarge
Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL
Machine Key Details
Make: Caterpillar
Model: D5N XL
Stock No: 10071
Year: 2005
Hours: 3251
Inspection report produced by an independent service and repair company based in Southampton.
SUBSCRIBE TO BE NOTIFIED WHEN NEW STOCK BECOMES AVAILABLE

Inspection Report

Inspected by an independent plant service and repair company.

General Condition


Overall condition: Machine looks very tidy, drives well. Track pads worn rest of undercarriage good.
Overall rating 4

Engine


Any blow by? None
4
Oil or fuel leaks No leaks
4
Caterpillar D5N XL
Click on a thumbnail to enlarge
Caterpillar D5N XL

Transmission


Gear change Good
4
Steering Good
4
Oil leaks None
4
General running condition Very good
4

U/C


Shoe width 560mm
Shoe height 30mm - 20% remaining
1.5
Rail height 100mm - 80% good
4
Pins and bushings 80% good (not turned)
4
Idler height 80% good
4
Top rollers 80% good
4
Bottom rollers 80% good.
4
Sprockets 80% good
4
Caterpillar D5N XL
Click on a thumbnail to enlarge
Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL

Cab


Lights All working
4
Wipers All working
4
Heater Working
4
A/C Working
4
Seat condition Good
4
Cladding condition Needs glueing back by the seat - to be fixed
3
Floor mat condition Good
4
Seat belt Good
4
Cab glass Good
4
Steps amd grab handles secure? Good
4
Caterpillar D5N XL
Click on a thumbnail to enlarge
Caterpillar D5N XL

Blade


Blade type PAT
Blade dimensions 3000mm x 1100mm
Cutting edges condition Need to be turned
2.5
Blade to arms pins, wear and shims Good
3.5
Trunions, wear and shims Good
3.5
General blade condition No marks or dents, edges need changing.
3.5
Caterpillar D5N XL
Click on a thumbnail to enlarge
Caterpillar D5N XL Caterpillar D5N XL Caterpillar D5N XL

Attachment


Ripper make Cat D5N SN 7JP00806
Number of tines 3
Wear in tine pins 80% good
4
Wear in mounting pins 80% good
4
General condition of blade. Very good.
4
Caterpillar D5N XL
Click on a thumbnail to enlarge

Panels & Paint/Decals


Any damage to panels No
4
Paint condition Good
4
Any decals ripped No
4

Dimensions


  Length Width Height
Shipping dimensions 5100mm 3000mm 3100mm
Haulage dimensions (blade turned) 5700mm 2900mm 3100mm
Outside to outside of tracks 2330mm
